CSPV-LF05 Closed Loop Hall Transducer
which can measure DC, AC, pulse and various irregular waveform currents under electrical isolation conditions
Higher accuracy and linearity
Short responding time and wide frequency band
Vibration resistance, water vapor proof and dust proof
Firm structure, low power consumption, smart size and light weight
Widely used in current monitoring devices, high current protection and other fields.
CSPV-LF05 Closed Loop Hall Transducer, AC, DC Measure
Rated Input Current (Ipn): 500A/1000A
Rated Measuring Current Range: ±1000A / ±1800A
Rated Output: 100 mA±0.2% / 200 mA±0.2%
Supply Voltage: ±15V～±24V±5%
Linearity: ≤0.1%
Zero offset current: ≤±0.2mA
Operating Temperature: -40℃~+85℃
