1. The Critical Challenge of DC Injection in Renewable Systems
Renewable energy systems, particularly solar PV and wind power installations, face a significant challenge with DC injection into AC grids. Inverters converting DC to AC can introduce residual DC components, which cause saturation in conventional current transformers (CTs), leading to measurement inaccuracies, false tripping, and potential grid instability. Oswell's DC-immuned current transformers address this through advanced core materials and innovative magnetic circuit designs that maintain linearity under DC bias conditions. These CTs can withstand DC components up to specified thresholds while delivering 0.1-class accuracy for precise energy metering and protection relay coordination. Their robust construction ensures reliable performance in harsh environments where temperature fluctuations and electromagnetic interference are common.
2. Technical Innovations in DC-Immune CT Design
Oswell's DC-immuned CTs incorporate multiple technological advancements to ensure stability. The core design utilizes specialized alloys with high saturation flux density, combined with precision winding techniques that minimize air gaps and leakage flux. Automatic winding processes guarantee uniformity in production, while vacuum epoxy potting eliminates moisture ingress and enhances thermal conductivity. These transformers feature wide operating temperature ranges (-40°C to +85°C) and excellent frequency characteristics, maintaining accuracy from 50Hz to 1kHz. With hipot test ratings of 4kV for 1 minute between primary and secondary circuits, they provide the necessary isolation for medium-voltage applications in solar farms, wind turbines, and EV charging stations.
3. Application Scenarios in Modern Energy Infrastructure
The implementation of DC-immuned CTs spans various renewable energy applications. In utility-scale solar plants, they enable accurate energy yield assessment and grid compliance monitoring. For wind farm collections systems, these CTs provide reliable current measurement for power conversion and distribution. They are equally crucial in commercial and residential settings, where rooftop solar installations require precise net metering and anti-islanding protection. With the growth of EV charging infrastructure, DC-immuned CTs ensure safe and accurate billing in fast-charging stations that integrate solar canopies. Their split-core versions facilitate easy retrofitting in existing infrastructure without power disruption, supporting the transition to smarter, more resilient grids.
Conclusion
DC-immuned current transformers represent a vital innovation in the integration of renewable energy sources. By addressing the critical issue of DC injection, these specialized components ensure measurement accuracy, system protection, and grid stability. As renewable penetration increases globally, Oswell's DC-immuned CTs will play an increasingly important role in enabling a reliable transition to sustainable energy systems, providing the precision and reliability needed for both utility-scale and distributed generation applications.
